安捷伦毛细管色谱柱Agilent DB-5 是非极性低流失柱，有多种柱尺寸可供选择。DB-5 柱也经过交联、键合，可耐受溶剂冲洗，可耐高温。
相似的固定相： SPB-5、Rtx-5、BP-5、OV-5、007-2(MPS-5)、SE-52、SE-54、XTI-5、PTE-5、ZB-5、AT-5、MDN-5、ZB-5
（5%-苯基）-甲基聚硅氧烷
非极性、低流失，具有高的温度上限
键合交联，可用溶剂冲洗
柱规格选择范围宽
应用范围广
优异的通用色谱柱
相当于 USP 固定相 G27
相似的固定相： SPB-5、Rtx-5、BP-5、OV-5、007-2(MPS-5)、SE-52、SE-54、XTI-5、PTE-5、ZB-5、AT-5、MDN-5、ZB-5
| 产品货号 | 规格描述 |
| 009-1075 | DB-5, 60m, 1.5um, with 0.5m deact |
| 121-5012 | DB-5 10m, 0.18mm, 0.18u |
| 121-5012E | 5in cage DB-5 10m, 0.18mm, 0.18um |
| 121-5012LTM | DB-5 10m, 0.18mm, 0.18um, LTM |
| 121-5013 | DB-5 10m, 0.18mm, 0.40u |
| 121-5013LTM | DB-5 10m, 0.18mm, 0.40um, LTM |
| 121-5022 | DB-5 20m, 0.18mm, 0.18u |
| 121-5022E | 5in cage DB-5 20m, 0.18mm, 0.18um |
| 121-5022LTM | DB-5 20m, 0.18mm, 0.18um, LTM |
| 121-5023 | DB-5 20m, 0.18mm, 0.40u |
| 121-5023E | 5in cage DB-5 20m,0.18mm,0.40um |
| 121-5023LTM | DB-5 20m, 0.18mm, 0.40um, LTM |
| 121-5042 | DB-5 40m,.18mm-.18u |
| 121-50H2 | DB-5 15m x 0.18mmID, 0.18um |
| 121-5522 | DB-5MS 20m, 0.18mm, 0.18u |
| 121-5522E | 5in cage DB-5MS 20m, 0.18mm, 0.18um |
| 121-5522LTM | DB-5MS 20m, 0.18mm, 0.18um, LTM |
| 121-5522UI | DB-5MS Ultra Inert 20m, 0.18mm, 0.18um |
| 121-5522UILTM | DB-5MS Ultra Inert 20m,0.18mm,0.18um,LTM |
| 121-5523 | DB-5ms 20m, 0.18mm, 0.36um |
| 121-5523LTM | DB-5MS 20m, 0.18mm, 0.36um, LTM |
| 121-5523UI | DB-5MS Ultra Inert 20m, 0.18mm, 0.36um |
| 121-5523UILTM | DB-5MS Ultra Inert 20m,0.18mm,0.36um,LTM |
| 121-5542 | DB-5MS 40m, 0.18mm, 0.18u |
| 121-5621 | DB-5.625 20m, 0.18mm, 0.18um |
| 121-5621LTM | DB-5.625 20m, 0.18mm, 0.18um, LTM |
| 121-5622 | DB-5.625 20m, 0.18mm, 0.36um |
| 121-5622LTM | DB-5.625 20m, 0.18mm, 0.36um, LTM |
| 122-5002LTM | DB-5 10 m, 0.25 mm, 0.25 um, LTM |
| 122-5011 | DB-5 15m, 0.25mm, 0.10u |
| 122-5011LTM | DB-5 15m, 0.25mm, 0.10um, LTM |
| 122-5012 | DB-5 15m, 0.25mm, 0.25u |
| 122-5012E | 5inch cage, DB-5 15m, 0.25mm, 0.25um |
| 122-5012LTM | DB-5 15m, 0.25mm, 0.25um, LTM |
| 122-5013 | DB-5 15m, 0.25mm, 1.00u |
| 122-5013E | 5inch cage, DB-5 15m, 0.25mm, 1.00um |
| 122-5013LTM | DB-5 15m, 0.25mm, 1.0um, LTM |
| 122-501E | DB-5 15m, 0.25mm, 0.5um 7inch cage |
| 122-501ELTM | DB-5 15m, 0.25mm, 0.50um, LTM |
| 122-5022 | DB-5 25m, 0.25mm, 0.25u |
| 122-5022LTM | DB-5 25m, 0.25mm, 0.25um, LTM |
| 122-5031 | DB-5 30m, 0.25mm, 0.10u |
| 122-5031LTM | DB-5 30m, 0.25mm, 0.10um, LTM |
| 122-5032 | DB-5 30m, 0.25mm, 0.25u |
| 122-5032E | 5inch cage DB-5 30m,.25mm,.25u |
| 122-5032LTM | DB-5 30m, 0.25mm, 0.25um, LTM |
| 122-5033 | DB-5 30m, 0.25mm, 1.00u |
| 122-5033E | 5inch cage, DB-5 30m, 0.25mm, 1.00um |
| 122-5033LTM | DB-5 30m, 0.25mm, 1.0um, LTM |
| 122-503E | DB-5 30m, 0.25mm, 0.5um 7inch cage |
| 122-503ELTM | DB-5 30m, 0.25mm, 0.50um, LTM |
| 122-5052 | DB-5 50m, 0.25mm, 0.25u |
| 122-5061 | DB-5 60m, 0.25mm, 0.10u |
| 122-5062 | DB-5 60m, 0.25mm, 0.25u |
| 122-5062E | 5inch cage, DB-5 60m, 0.25mm, 0.25um |
| 122-5063 | DB-5 60m, 0.25mm, 1.00u |
| 122-5063E | 5inch cage, DB-5 60m, 0.25mm, 1.00um |
| 122-506E | DB-5 60m, 0.25mm, 0.5um 7inch cage |
| 122-5511 | DB-5MS 15m, 0.25mm, 0.10u |
| 122-5511LTM | DB-5MS 15m, 0.25mm, 0.10um, LTM |
| 122-5512 | DB-5MS 15m, 0.25mm, 0.25u |
| 122-5512E | 5in cage DB-5MS 15m, 0.25mm, 0.25um |
| 122-5512LTM | DB-5MS 15m, 0.25mm, 0.25um, LTM |
| 122-5512UI | DB-5MS Ultra Inert 15m, 0.25mm, 0.25um |
| 122-5512UILTM | DB-5MS Ultra Inert 15m,0.25mm,0.25um,LTM |
| 122-5513 | DB-5MS 15m, 0.25mm, 1.00u |
| 122-5513LTM | DB-5MS 15m, 0.25mm, 1.0um, LTM |
| 122-5513UI | DB-5MS Ultra Inert 15m, 0.25mm, 1.0um |
| 122-5513UILTM | DB-5MS Ultra Inert 15m,0.25mm,1.0um,LTM |
| 122-5516 | DB-5MS 15m, 0.25mm, 0.50u |
| 122-5516LTM | DB-5MS 15m, 0.25mm, 0.50um, LTM |
| 122-5522 | DB-5MS 25m, 0.25mm, 0.25u |
| 122-5522LTM | DB-5MS 25m, 0.25mm, 0.25um, LTM |
| 122-5522UI | DB-5MS Ultra Inert 25m, 0.25mm, 0.25um |
| 122-5522UILTM | DB-5MS Ultra Inert 25m,0.25mm,0.25um,LTM |
| 122-552ALTM | DB-5MS 25m, 0.25mm, 0.40um, LTM |
| 122-5531 | DB-5MS 30m, 0.25mm, 0.10u |
| 122-5531LTM | DB-5MS 30m, 0.25mm, 0.10um, LTM |
| 122-5532 | DB-5MS 30m, 0.25mm, 0.25u |
| 122-5532E | 5in cage, DB-5MS 30m, 0.25mm, 0.25um |
| 122-5532G | DB-5MS 30m, 0.25mm, 0.25um, 10m DRGRD |
| 122-5532LTM | DB-5MS 30m, 0.25mm, 0.25um, LTM |
| 122-5532UI | DB-5MS Ultra Inert 30m, 0.25mm, 0.25um |
| 122-5532UIE | 5in cage, DB-5MS UI 30m, 0.25mm, 0.25um |
| 122-5532UILTM | DB-5MS Ultra Inert 30m,0.25mm,0.25um,LTM |
| 122-5533 | DB-5MS 30m, 0.25mm, 1.00u |
| 122-5533E | 5inch cage, DB-5MS 30m, 0.25mm, 1 |
| 122-5533G | DB-5MS 30m, 0.25mm, 1.00um, 10m DRGRD |
| 122-5533LTM | DB-5MS 30m, 0.25mm, 1.0um, LTM |
| 122-5533UI | DB-5MS Ultra Inert 30m, 0.25mm, 1.0um |
| 122-5533UIE | 5in cage, DB-5MS UI 30m, 0.25mm, 1.0um |
| 122-5533UILTM | DB-5MS Ultra Inert 30m,0.25mm,1.0um,LTM |
| 122-5536 | DB-5MS 30m, 0.25mm, 0.50u |
| 122-5536E | 5inch cage, DB-5MS 30m, 0.25mm, 0.50um |
| 122-5536G | DB-5MS 30m, 0.25mm, 0.50um, 10m DRGRD |
| 122-5536LTM | DB-5MS 30m, 0.25mm, 0.50um, LTM |
| 122-5536UI | DB-5MS Ultra Inert 30m, 0.25mm, 0.50um |
| 122-5536UILTM | DB-5MS Ultra Inert 30m,0.25mm,0.50um,LTM |
| 122-5552 | DB-5MS 50m, 0.25mm, 0.25u |
| 122-5552UI | DB-5MS Ultra Inert 50m, 0.25mm, 0.25um |
| 122-5561 | DB-5MS 60m, 0.25mm, 0.10u |
| 122-5562 | DB-5MS 60m, 0.25mm, 0.25u |
| 122-5562E | 5inch cage, DB-5MS 60m, 0.25mm, 0.25um |
| 122-5562G | DB-5MS 60m, 0.25mm, 0.25um, 10m DRGRD |
| 122-5562UI | DB-5MS Ultra Inert 60m, 0.25mm, 0.25um |
| 122-5563 | DB-5MS 60m, 0.25mm, 1.00u |
| 122-5563UI | DB-5MS Ultra Inert 60m, 0.25mm, 1.0um |
| 122-5631 | DB-5.625 30m, 0.25mm, 0.25u |
| 122-5631G5 | DB-5.625, 30m, 0.25mm, 0.25um, 5m DRGD |
| 122-5631LTM | DB-5.625 30m, 0.25mm, 0.25um, LTM |
| 122-5632 | DB-5.625 30m, 0.25mm, 0.50u |
| 122-5632LTM | DB-5.625 30m, 0.25mm, 0.50um, LTM |
| 122-5633 | DB-5.625 30m, 0.25mm, 1.00u |
| 122-5633LTM | DB-5.625 30m, 0.25mm, 1.0um, LTM |
| 122-5661 | DB-5.625 60m,.25mm-.25u |
| 122-5711 | DB-5HT 15m, 0.25mm, 0.10u |
| 122-5711E | 5inch cage, DB-5HT 15m, 0.25mm, 0.10um |
| 122-5711LTM | DB-5HT 15m, 0.25mm, 0.10um, LTM |
| 122-5731 | DB-5HT 30m, 0.25mm, 0.10u |
| 122-5731LTM | DB-5HT 30m, 0.25mm, 0.10um, LTM |
| 123-1464 | DB-502.2 60m, 0.32mm, 1.80u |
| 123-5003LTM | DB-5 5m, 0.32mm, 1.0um, LTM |
| 123-500E | DB-5 10m, 0.32mm, 0.50um, 7in cage |
| 123-500ELTM | DB-5 10m,0.32mm,0.50um,LTM |
| 123-5011 | DB-5 15m, 0.32mm, 0.10u |
| 123-5011LTM | DB-5 15m, 0.32mm, 0.10um, LTM |
| 123-5012 | DB-5 15m, 0.32mm, 0.25u |
| 123-5012E | 5inch cage, DB-5 15m,.32mm,.25u |
| 123-5012LTM | DB-5 15m, 0.32mm, 0.25um, LTM |
| 123-5013 | DB-5 15m, 0.32mm, 1.00u |
| 123-5013E | 5inch cage, DB-5 15m, 0.32mm, 1.00um |
| 123-5013LTM | DB-5 15m, 0.32mm, 1.0um, LTM |
| 123-5022 | DB-5 25m,.32mm-.25u |
| 123-5022LTM | DB-5 25m, 0.32mm, 0.25um, LTM |
| 123-5026 | DB-5 25m, 0.32mm, 0.52u |
| 123-5026LTM | DB-5 25m, 0.32mm, 0.52um, LTM |
| 123-502D | DB-5 25m,.32mm-.17u |
| 123-502DLTM | DB-5 25m, 0.32mm, 0.17um, LTM |
| 123-502F | DB-5 25m,.32mm-1.05u |
| 123-502FLTM | DB-5 25m, 0.32mm, 1.05um, LTM |
| 123-5031 | DB-5 30m, 0.32mm, 0.10u |
| 123-5031LTM | DB-5 30m, 0.32mm, 0.10um, LTM |
| 123-5032 | DB-5 30m, 0.32mm, 0.25u |
| 123-5032E | 5inch cage DB-5, 0.32mm,30m,0.25um |
| 123-5032LTM | DB-5 30m, 0.32mm, 0.25um, LTM |
| 123-5033 | DB-5 30m, 0.32mm, 1.00u |
| 123-5033E | 5inch cage, DB-5 30m, 0.32mm, 1.00um |
| 123-5033LTM | DB-5 30m, 0.32mm, 1.0um, LTM |
| 123-503B | DB-5 30m,.32mm-1.5u |
| 123-503BLTM | DB-5 30m, 0.32mm, 1.50um, LTM |
| 123-503E | DB-5 30m, 0.32mm, 0.5um, 7inch cage |
| 123-503ELTM | DB-5 30m, 0.32mm, 0.50um, LTM |
| 123-5052 | DB-5 50m,.32mm-.25u |
| 123-5053 | DB-5 50m, 0.32mm, 1.00u |
| 123-5056 | DB-5 50m,.32mm-.52u |
| 123-5062 | DB-5 60m, 0.32mm, 0.25u |
| 123-5063 | DB-5 60m, 0.32mm, 1.00u |
| 123-5063E | 5inch cage, DB-5 60m, 0.32mm, 1.00um |
| 123-5511 | DB-5MS 15m, 0.32mm, 0.10u |
| 123-5511LTM | DB-5MS 15m, 0.32mm, 0.10um, LTM |
| 123-5512 | DB-5MS 15m, 0.32mm, 0.25u |
| 123-5512LTM | DB-5MS 15m, 0.32mm, 0.25um, LTM |
| 123-5513 | DB-5MS 15m, 0.32mm, 1.00u |
| 123-5513E | 5inch cage DB-5MS 15m, 0.32mm, 1.00um |
| 123-5513LTM | DB-5MS 15m, 0.32mm, 1.0um, LTM |
| 123-5526 | DB-5MS 25m, 0.32mm, 0.52u |
| 123-5526LTM | DB-5MS 25m, 0.32mm, 0.52um, LTM |
| 123-5531 | DB-5MS 30m, 0.32mm, 0.10u |
| 123-5531LTM | DB-5MS 30m, 0.32mm, 0.10um, LTM |
| 123-5532 | DB-5MS 30m, 0.32mm, 0.25u |
| 123-5532E | 5inch cage DB-5ms, 0.32mm, 30m, 0.25mm |
| 123-5532LTM | DB-5MS 30m, 0.32mm, 0.25um, LTM |
| 123-5532UI | DB-5MS Ultra Inert 30m, 0.32mm, 0.25um |
| 123-5532UIE | 5in cage, DB-5MS UI 30m, 0.32mm, 0.25um |
| 123-5532UILTM | DB-5MS Ultra Inert 30m,0.32mm,0.25um,LTM |
| 123-5533 | DB-5MS 30m, 0.32mm, 1.00u |
| 123-5533G | DB-5MS 30m, .32mm, 1u, 10m Duraguard |
| 123-5533LTM | DB-5MS 30m, 0.32mm, 1.0um, LTM |
| 123-5533UI | DB-5MS Ultra Inert 30m, 0.32mm, 1.0um |
| 123-5533UILTM | DB-5MS Ultra Inert 30m,0.32mm,1.0um,LTM |
| 123-5536 | DB-5MS 30m, 0.32mm, 0.50u |
| 123-5536LTM | DB-5MS 30m, 0.32mm, 0.50um, LTM |
| 123-5536UI | DB-5MS Ultra Inert 30m, 0.32mm, 0.50um |
| 123-5536UILTM | DB-5MS Ultra Inert 30m,0.32mm,0.50um,LTM |
| 123-5561 | DB-5MS 60m, 0.32mm, 0.10u |
| 123-5562 | DB-5MS 60m, 0.32mm, 0.25u |
| 123-5563 | DB-5MS 60m, 0.32mm, 1.00u |
| 123-5563UI | DB-5MS Ultra Inert 60m, 0.32mm, 1.0um |
| 123-5566 | DB-5MS 0.32mm, 60m, 0.5um |
| 123-5701 | DB-5ht 10m, 0.32mm, 0.10um |
| 123-5701LTM | DB-5HT 10m, 0.32mm, 0.10um, LTM |
| 123-5711 | DB-5HT 15m, 0.32mm, 0.10u |
| 123-5711E | 5inch cage, DB-5HT 15m, 0.32mm, 0.10um |
| 123-5731 | DB-5HT 30m, 0.32mm, 0.10u |
| 123-5731E | 5inch cg DB-5HT 30m, 0.32mm, 0.10um |
| 123-5731LTM | DB-5HT 30m, 0.32mm, 0.10um, LTM |
| 124-5012LTM | DB-5 15m, 0.45mm, 1.27um, LTM |
| 124-5032 | DB-5 30m, 0.45mm, 1.27u |
| 124-5032LTM | DB-5 30m, 0.45mm, 1.27um, LTM |
| 124-5037 | DB-5 30m,.45mm-.42u |
| 124-5037LTM | DB-5 30m, 0.45mm, 0.42um, LTM |
| 125-5012 | DB-5 15m, 0.53mm, 1.50u |
| 125-5012E | 5inch cage, DB-5 15m, 0.53mm, 1.50um |
| 125-5012LTM | DB-5 15m, 0.53mm, 1.50um, LTM |
| 125-5017 | DB-5 15m, 0.53mm, 0.50u |
| 125-5017LTM | DB-5 15m, 0.53mm, 0.50um, LTM |
| 125-501J | DB-5 15m, 0.53mm, 1.00u |
| 125-501JLTM | DB-5 15m, 0.53mm, 1.0um, LTM |
| 125-501K | DB-5 15m, 0.53mm, 0.25u |
| 125-501KLTM | DB-5 15m, 0.53mm, 0.25um, LTM |
| 125-5025 | DB-5 25m,.53mm-5.0u |
| 125-5025LTM | DB-5 25m, 0.53mm, 5.00um, LTM |
| 125-5032 | DB-5 30m, 0.53mm, 1.50u |
| 125-5032E | 5in cage, DB-5 30m, 0.53mm, 1.50 |
| 125-5032LTM | DB-5 30m, 0.53mm, 1.50um, LTM |
| 125-5034 | DB-5 30m, 0.53mm, 3.00u |
| 125-5034E | 5inch cage DB-5 30m, 0.53mm, 3.00um |
| 125-5034LTM | DB-5 30m, 0.53mm, 3.00um, LTM |
| 125-5035 | DB-5 30m, 0.53mm, 5.00u |
| 125-5035E | 5inch cage, DB-5 30m, 0.53mm, 5.00um |
| 125-5035LTM | DB-5 30m, 0.53mm, 5.00um, LTM |
| 125-5037 | DB-5 30m, 0.53mm, 0.50u |
| 125-5037E | 5inch cage, DB-5 30m, 0.53mm, 0.50um |
| 125-5037LTM | DB-5 30m, 0.53mm, 0.50um, LTM |
| 125-503B | DB-5 30m,.53mm-2.65u |
